Open Frame Touch Monitor KOT-170P-023
KOT-170P-0231.Adopt KeeTouch capacitive touch technology, with stable and sensitive touch exp erience and high-definition visual enjoyment
2.With pure flat and narrow-edge design, support ten-point touch
3.With tempered glass cover, dustproof, anti-vandal, anti-scratch, life span is more t han 50 million times
-
17 Inch PCAP Touch Monitor With Peep-proof Film：
1.With PCAP touch screen, fast response and great touch experience
2.1280x1024 high resolution, 1000:1 high contrast with high image quality
3.Anti-glare, vandal-proof and IP65 waterproof PCAP touch monitor
4.VGA&DVI interfaces, USB port for touch
5.With peep-proof protection film and sun protection film
6.Multiple mounting options include VESA mount, horizontal and vertical brackets mount
7.Operation system: XP, WIN7, WIN8, WIN10, Linux, Android
8.Other sizes can be offered (7’’- 43’’).
FAQ:1. Are you a manufacturer?Yes, KeeTouch is a professional touch product manufacturer with nearly 20 years of experience, located in Shenzhen, China.2. What’s your MOQ for the PCAP Touch Monitor?Our minimum order quantity is 1pc only.3. What is your warranty period for the PCAP Touch Monitor?Our regular warranty is 12 months for all the products, with 2-3 years Warranty (optional).4. Can you produce the PCAP Touch Monitor according to the customer's requirements?Sure, with 40+ Professional R & D engineers, OEM and ODM are welcomed.
-
Complete Machine
Model No.
KOT-0170U-CA4P (P/N:KOT-170P-023)
Series
OT
Display Type
5:4 Ratio 17" TFT-LCD
Active Area
337.9*270.3(mm)
Monitor Dimensions (W*H*D)
395.3*327.7*59.2(mm)
Suggested Resolution
1280*1024 @ 60Hz
Support Colors
16.7M
Pure LCD Panel
400cd/m²
Brightness (Typ.)
With Touch Monitor
145cd/m²
Response Time (Typ.)
5ms
Viewing Angle(Typ.at CR＞10)）
Horizontal(left/right)
85°/85°
Vertical(up/down)
80°/80°
Contrast Ratio (Typ.)
1000:01:00
Video Input
VGA/DVI
Frequency (H/V)
37.9～80KHz / 60～75Hz
Type: External brick
Power Supply
Display voltage: DC 12V 3A±5%
Input (line) voltage: 100-240 V/AC, 50-60 Hz Power Adapter DC Head Inner Diameter:2.1mm
Operating Temp.
0～50°C
Operating RH
20%～80%
Environment
Storage Temp.
-20～60°C
Storage RH
10%～90%
MTBF
≥30,000 Hours
LED Back Light Life (Typ.)
≥30,000 Hours
Weight（N.W/G.W）
4.65Kg(1pcs)/10.25Kg(2 pcs in one package)
Package dimensions
466*185*403(mm)(2 pcs in one package)
Power Consumption
Standby Power: ≤0.82W / Operating Power: ≤7.3W
1. VESA 75mm
Mount Interface
2. Mount bracket, horizontal or vertical mount
Buttons
AUTO,+,POWER,-,MENU
OSD Control
Function
Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset
CCC, UL, FCC, CE, CB, RoHS
Regular Warranty
1 year
Touch Screen
Touch Type
17" Capacitive touch screens
Touch input
USB
Response Time
≤10ms
Hardness
6H
Light Transmittance
≥83%
Support System
XP,WIN7,WIN8,WIN10,Linux,Android
Active Area
340.92*273.34(mm)
Thickness
3.9±0.3(mm)
Touch Test
≥50,000,000 次
Input Voltage
DC 5V±5%
-
