Infrared Touch Monitor KOT-0190U-IR3W
KOT-0190U-IR3W1.Integrated with Keetouch IR touch panel for the ultimate in image quality.
2.Future generation panels phased-in without external changes
3.Service life: ≥50,000,000 times.
-
Infrared Touch Monitor Main Features:
1、Infrared touch screen, accurate touch, fast response, 1- 40 points optional
2、High resolution, high contrast infrared touch monitor, high definition visual enjoyment
3、IP65 front frame waterproof, anti-vandal Infrared Touch Monitor
4、Industrial grade infrared touch monitor, lasting touch, durable even in harsh environment
5、Multiple mounting options include VESA mount, horizontal or vertical brackets mount
6、VGA interface, USB for touch input
7、Support system: XP, WIN7, WIN8, Linux
8、Other sizes can be offered (7’’- 32’’)
FAQ:1. Are you a manufacturer?Yes, KeeTouch is a professional touch product manufacturer with nearly 20 years of experience, located in Shenzhen, China.2.What’s your MOQ?Our minimum order quantity is 1pc only.3.What is your warranty period?Our regular warranty is 12 months for all the products, with 2-3 years Warranty (optional).4.Can you produce the product according to the customer's requirements?Sure, with 40+ Professional R&D engineers, OEM and ODM are offered.5.What is your payment method?We can accept T/T, Western Union, Paypal, Pay Later, Credit card, Boleto, e-Checking and Alipay. ( L/C can be negotiable. )6.What is your delivery time?7. 3-5 work days for inventory orders, 7-15 business days for bulk production. -
Complete Machine
Model No.
KOT-0190U-IR3W (KOT-190p-042）
Series
Metal Frame, OT
Display Type
19＂Active Matrix TFT -LCD，
Active Area
14.8＂(377mm)×11.9＂(301mm)
Suggested Resolution
1280x1024 @ 60Hz
Support Colors
16.7M
Brightness (Typ.)
Pure LCD Panel
250cd/m²
With Touch Monitor
225cd/m²
Response Time (Typ.)
16ms
Viewing Angle(Typ.at CR＞10)）
Horizontal(left/right):85°/85°
Vertical(up/down): 80°/80°
Contrast Ratio (Typ.)
1000:01:00
Video Input
Analog RGB
Frequency (H/V)
30～80KHz / 60～75Hz
Power Supply
Type: External brick
Display voltage: DC 12V±5%
Input (line) voltage: 100-240 VAC, 50-60 Hz
Environment
Operating Temp.
0～50°C
Operating RH
20%～80%
Storage Temp.
-20～60°C
Storage RH
10%～90%
MTBF
≥50,000 Hours
LED Back Light Life (Typ.)
≥50,000 Hours
Weight（N.W/G.W）
5.85Kg
Power Consumption
Operating Power: ≤15W
Mount Interface
1.VESA 75*75mm and 100*100mm
OSD Control
Buttons
AUTO,+,POWER,-,MENU
Function
Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset
Touch Type
19" Infrared touch screens
Touch Input
USB
Response Time
≤16ms
Support System
XP,WIN7,WIN8,Linux
CCC, UL, FCC, CE, CB, RoHS
Regular Warranty
1 year
-
