High Brightness Touch Monitor KOT-0150U-CA4PH
KOT-0150U-CA4PH1.KeeTouch water proof capacitive sensor allows wet finger operation, provides high quality touch experience even in harsh environment.
3.Anti-glare tempered cover glass.
4.IP65（front surface）
-
High Brightness Touch Monitor Main Features Main features:
1、PCAP multi-touch high brightness touch monitor, great interactive experience
2、Readable under direct sunlight, 1000 - 2000cd/m²available
3、High resolution, high clarity image with wide viewing angle
4、Anti-glare,vandal-proof and dust-proof
5、Pure flat designed high brightness touch monitor with IP65 water-proof function
6、VGA + DVI interfaces,USB for touch
7、Operation system: Windows 7,Windows 8 and Windows 10
8、Other sizes are optional (8’’- 43’’)
FAQ:1. Are you a manufacturer?Yes, KeeTouch is a professional touch product manufacturer with nearly 20 years of experience, located in Shenzhen, China.2. What’s your MOQ for the high brightness touch monitor?Our minimum order quantity is 1pc only.3. What is your warranty period for the high brightness touch monitor?Our regular warranty is 12 months for all the products, with 2-3 years Warranty (optional).4. Can you produce the high brightness touch monitor according to the customer's requirements?Sure, with 40+ Professional R & D engineers, OEM and ODM are offered.5. What is your payment method?We can accept T/T, Western Union, Paypal, Pay Later, Credit card, Boleto, e-Checking and Alipay. ( L/C can be negotiable. )6. What is your delivery time?3-5 work days for inventory orders, 7-15 business days for bulk production. -
Complete Machine
Model No.
KOT-0150U-CA4PH（KOT-150P-014-02）
Series
OT
Display Type
5 : 4 Ratio 15" TFT-LCD
Active Area
304.1*228.1 (mm)
Monitor Dimensions (W*H*D)
353.5*284.5*65.3 (mm)
Suggested Resolution
1024*768 @ 60Hz
Support Colors
16.7M
Brightness (Typ.)
Pure LCD Panel
1000cd/m²
With Touch Monitor
830cd/m²
Response Time (Typ.)
21ms
Viewing Angle(Typ.at CR＞10)）
Horizontal(left/right)
80°/80°
Vertical(up/down)
80°/80°
Contrast Ratio (Typ.)
1800:01:00
Video Input
VGA/DVI
Frequency (H/V)
40～90KHz / 55～70Hz
Power Supply
Type: External brick
Display voltage: DC 12V±5%
Input (line) voltage: 100-240 VAC, 50-60 Hz
Environment
Operating Temp.
-20～50°C
Operating RH
20%～90%
Storage Temp.
-20～60°C
Storage RH
10%～90%
MTBF
30,000 Hours
LED Back Light Life (Typ.)
30,000 Hours
OSD Control
Buttons
AUTO,+,POWER,-,MENU
Function
Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset
Weight（N.W/G.W）
4.95Kg(1pcs)
Package dimensions
495*250*425(mm)(2pcs in one package)
CCC, ETL, FCC, CE, CB, RoHS
Touch screen Type
15”Projected Capacitive Touchscreen
Touch System Interface
USB(or Serial port,one point)
Support System
10 points in win7
Regular Warranty
1 year
-
